. . | CPU | . . . - Support for Intel® Core™ i7 processors/Intel® Core™ i5 processors/ Intel® Core™ i3 processors/Intel® Pentium®processors/ Intel® Celeron® processors in the LGA1151 package
. - L3 cache varies with CPU
. . (Please refer ''CPU Support List'' for more information.) | .
. . | Chipset | . . . - Intel® H110 Express Chipset
. . | .
. . | Memory | . . . - 2 x DDR4 DIMM sockets supporting up to 32 GB of system memory. * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
. - Dual channel memory architecture
. - Support for DDR4 2133 MHz memory modules
. - Support for ECC UDIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
. - Support for non-ECC UDIMM 1Rx8/2Rx8/1Rx16 memory modules
. . (Please refer ''Memory Support List'' for more information.) | .
. . | Onboard Graphics | . Integrated Graphics Processor-Intel® HD Graphics support. . - 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
. - 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz. * Support for HDMI 1.4 version.
. . Support for up to 2 displays at the same time. Maximum shared memory of 1024 MB | .
. . | Audio | . . . - Realtek® ALC892 codec
. - High Definition Audio
. - 2/4/5.1/7.1-channel. * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
. - Support for S/PDIF Out
. . | .
. . | LAN | . . . - Intel® GbE LAN chip (10/100/1000 Mbit)
. . | .
. . | Expansion Slots | . . . - 1 x PCI Express x16 slot, running at x16. (The PCI Express x16 slot conforms to PCI Express 3.0 standard.)
. - 2 x PCI Express x1 slots. (The PCI Express x1 slots conform to PCI Express 2.0 standard.)
. . | .
. . | Storage Interface | . Chipset:. . - 4 x SATA 6Gb/s connectors
. . | .
. . | USB | . Chipset:. . - 4 x USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header)
. - 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
. . | .
. . | Internal I/O Connectors | . . . - 1 x 24-pin ATX main power connector
. - 1 x 4-pin ATX 12V power connector
. - 4 x SATA 6Gb/s connectors
. - 1 x CPU fan header
. - 1 x system fan header
. - 1 x front panel header
. - 1 x front panel audio header
. - 1 x S/PDIF Out header
. - 1 x USB 3.0/2.0 header
. - 2 x USB 2.0/1.1 headers
. - 1 x Trusted Platform Module (TPM) header
. - 1 x Clear CMOS jumper
. . | .
. . | Back Panel Connectors | . . . - 1 x PS/2 keyboard port
. - 1 x PS/2 mouse port
. - 1 x D-Sub port
. - 1 x HDMI port
. - 2 x USB 3.0/2.0 ports
. - 2 x USB 2.0/1.1 ports
. - 1 x RJ-45 port
. - 3 x audio jacks (Line In, Line Out, Mic In)
. . | .
. . | I/O Controller | . . . - iTE® I/O Controller Chip
. . | .
. . | H/W Monitoring | . . . - System voltage detection
. - CPU/System temperature detection
. - CPU/System fan speed detection
. - CPU/System overheating warning
. - CPU/System fan fail warning
. - CPU/System fan speed control. * Whether the fan speed control function is supported will depend on the cooler you install.
. . | .
. . | BIOS | . . . - 1 x 64 Mbit flash
. - Use of licensed AMI UEFI BIOS
. - PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
. . | .
. . | Unique Features | . . . - Support for APP Center. * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.. 3D OSD. @BIOS. AutoGreen. Cloud Station. EasyTune. Fast Boot. ON/OFF Charge. Smart TimeLock. Smart Keyboard. Smart Backup. System Information Viewer. USB Blocker
. - Support for Q-Flash
. - Support for Smart Switch
. - Support for Xpress Install
. . | .
. . | Bundle Software | . . . - Norton® Internet Security (OEM version)
. - cFosSpeed
. . | .
. . | Operating System | . . . - Support for Windows 10/8.1 64-bit
. - Support for Windows 7 32-bit/64-bit. * Please download the ''Windows USB Installation Tool'' from GIGABYTE's website and install it before installing Windows 7.
. . | .
. . | Form Factor | . . . - Micro ATX Form Factor; 22.6cm x 17.4cm
. . | .
. . | Remark | . . . - Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
. - Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
. . | .
. .
